System: 1) Storage Cylinder Capacity: 40-180 Litters2) Filling Pressure: 4.2MPa3) Max. Working Pressure (@50℃): 5.3MPa4) Concentration (kg/m³): η＜＝9505) Working Voltage & Current: DC24V, 1.3A6) Ambient Temperature: 0~50℃7) Spray Duration: ＜＝10S8) Start-up Methods: Automatic Electric, Manual Electric or Physical Manual.9) Automatic Start-up Delay Time: Adjustable From 0-30s Cylinder: 1) Cylinder Volume: L2) Fill in Gas: kg3) Material:  steel cylinder，brass head valve4) Rated / Max. Working Pressure: 2.5MPa/4.2MPa5) Safety Valve:  5.0+/-0.25MPa6) Surface:  painting red or customized colour7) Accessories:  including one cylinder, head valve, siphon tube, pressure gauge.

1) Inlet flange:  DN1002) Flange holes match to: PN16 / BS4504 / EN1092 / DIN25023) Rated working pressure: 0.8MPa4) Working pressure range: 0.8~1.2MPa5) Material: aluminium body, stainless steel nozzle6) Flow per second: 24L/s, 32L/s, 40L/s7) Horizontal & vertical adjustment angle: 0 ~ 360° & -70° ~ +70°8) Ejection distance: 24L/s＞＝45m; 32L/s＝50m 1) Inlet flange:  DN1002) Flange holes match to: PN16 / BS4504 / EN1092 / DIN25023) Rated working pressure: 1.0MPa4) Working pressure range: 1.0~1.6MPa5) Material: aluminium body, stainless steel nozzle6) Flow per second: 48L/s, 60L/s7) Horizontal & vertical adjustment angle: 0 ~ 360° & -70° ~ +70°8) Ejection distance: 48L/s＝60m...

1) Inlet Flange: DN1002) Flange Holes Match to: PN16 / BS4504 / EN1092 / DIN25023) Rated Working Pressure: 0.8MPa4) Working Pressure Range: 0.8~1.6MPa5) Material: aluminium6) Flow Per Second: 20L/s, 30L/s, 40L/s, 50L/s7) Horizontal & Vertical Adjustment Angle: 0 ~ 360° & -70° ~ +70°8) Ejection Distance: 20L/s＞＝48m；30L/s＞＝55m；40L/s＞＝60m

1) Flow Rate: 20L/s, 30L/s, 40L/s, 50L/s, 80L/s2) Inlet Flange:  20L and 30L=DN65                           40L, 50L and 80L=DN1003) Flange Holes Match to: PN16 / BS4504 / EN1092 / DIN25024) Rated Working Pressure: 20L and 30L=0.8MPa                                                   40L and 50L=0.9MPa                                                   80L=1.0MPa5) Working Pressure Range: 20L and 30L=0.6-1.0MPa                                                     40L and 50L=0.8-1.2MPa                                                     80L=0.8-1.2MPa6) Ejection Distance: 20L and 30L≥55m                                      40L≥65m                                      50L≥75m                                      80L≥90m7) Material: SS304 water way, aluminum alloy nozzle, powder coated red.8) Horizontal & Vertical Swinging Angle: 0 ~ 360° & -60° ~ +90°9) Water Outlet Mode: Jet or Fog10) Fog Angle: 100°11) Control Mode: Electric control (wired + wireless)

1) Inlet Flange: DN1002) Flange Holes Match to: PN16 / BS4504 / EN1092 / DIN25023) Rated Working Pressure: 0.8MPa4) Working Pressure Range: 0.8~1.6MPa5) Material: aluminium6) Flow Per Second: 20L/s, 30L/s, 40L/s, 50L/s7) Horizontal & Vertical Adjustment Angle: 0 ~ 360° & -70° ~ +70°8) Ejection Distance: 20L/s＞＝48m；30L/s＞＝55m；40L/s＞＝60m
