System:
1) Storage Cylinder Capacity: 40-180 Litters
2) Filling Pressure: 4.2MPa
3) Max. Working Pressure (@50℃): 5.3MPa
4) Concentration (kg/m³): η＜＝950
5) Working Voltage & Current: DC24V, 1.3A
6) Ambient Temperature: 0~50℃
7) Spray Duration: ＜＝10S
8) Start-up Methods: Automatic Electric, Manual Electric or Physical Manual.
9) Automatic Start-up Delay Time: Adjustable From 0-30s
Cylinder:
1) Cylinder Volume: L
2) Fill in Gas: kg
3) Material: steel cylinder，brass head valve
4) Rated / Max. Working Pressure: 2.5MPa/4.2MPa
5) Safety Valve: 5.0+/-0.25MPa
6) Surface: painting red or customized colour
7) Accessories: including one cylinder, head valve, siphon tube, pressure gauge.
