User-Customized, Non-rising Stem Gate Valve, Flange Connection.
1) Size: DN40 to DN600 (1-1/2" to 24")2) Working Pressure: 1.6MPa / 16bar / 235psi3) Sealing Test Pressure: 1.76MPa4) Strength Test Pressure: 2.4MPa5) Material: ductile cast iron body, 2cr13 stem, NBR + DI seat, ductile cast iron handwheel6) Finishing: epoxy resin coated red, blue or customized color.7) Applicable Medium: water / foam liquid8) Working Temperature: 0℃～80℃(176°F)9) Flange Holes Match to: BS4504 / EN1092 / DIN2502
Flanged Y-strainer.
1) Size: DN50-DN300(2"-12")2) Nominal Pressure: 1.6MPa3) Sealing Test Pressure: 1.76MPa4) Shell Test Pressure: 2.4MPa5) Applicable Temperature: 0~80℃6) Fluid Medium: Water7) Material: DI Body Epoxy Resin Coated Red or Blue, Stainless Steel Filter Mesh, Steel Nut.8) Flange Holes Match To: PN16 / BS4504 / EN1092 / DIN2502
Grooved Y-strainer
1) Size: DN65-DN2002) Nominal Pressure: 1.6MPa3) Sealing Test Pressure: 1.76MPa4) Shell Test Pressure: 2.4MPa5) Applicable Temperature: 0~80℃6) Fluid Medium: Water7) Material: DI Body Epoxy Resin Coated Red, Stainless Steel Mesh, Steel Nut.8) Connecting Diameter(2.5"-8"): (73 , 76.1)(88.9)(108 , 114.3)(133 , 139.7 , 141.3)(159 , 165.1 , 168.3)(219.1)
Swing Check Valve / Non-Return Valve
1) Size: DN50-DN2002) Nominal Pressure: 1.6MPa3) Testing Pressure: 1.8MPa4) Applicable Temperature: 0~80℃5) Fluid Medium: Water6) Material: DI Body Epoxy Resin Coated Red or Blue, DI Disc Cover With NBR7) Flange Holes Match To: BS4504 / EN1092 / DIN2502
Grooved Swing Check Valve
1) Size: DN50-DN2002) Nominal Pressure: 1.6MPa3) Testing Pressure: 1.8MPa4) Applicable Temperature: 0~80℃5) Fluid Medium: Water6) Material: DI Body Epoxy Resin Coated Red, DI Disc Rubber Coated, Steel Nut.7) Connecting Diameter(2"-8"): (60.3)(73 , 76.1)(88.9)(108 , 114.3)(133 , 139.7 , 141.3)(159 , 165.1 , 168.3)(219.1)
